Telit Wireless Solutions—Geo-Location SoC Unwrapped (Multi-GNSS)

[SatNews] Telit Wireless Solutions has introduced their Jupiter SL869 V2, the second generation of one of its top performing positioning products—this new module is based on the low-power MT3333 from MediaTek.

The complete multi-GNSS receiver features easy integration and superior battery-life performance, able to discover and simultaneously track multiple constellations. It also delivers a high-sensitivity RF front-end, enhancing reliability and functionality of geo-location aware consumer, commercial and industrial devices.

The Jupiter SL869 V2 supports GPS, QZSS and Glonass and is ready for Galileo and Compass/Beidou. Two variants of product deliver simultaneously tracking of different combinations of constellations: either GPS + Galileo and Glonass; or GPS + Galileo and Compass/Beidou. Geo-location data is delivered using NMEA protocol through a standard UART port. It supports ephemeris file injection (A-GPS) as well as Satellite Based Augmentation System (SBAS) to increase position accuracy. Its onboard software engine is able to locally predict ephemeris three days in advance starting from ephemeris data broadcast by GNSS satellites, received by the module and stored in the internal Flash memory.
The SL869 V2 can replace the JN3 or SL869 in device designs with the observance of a few simple application rules. That allows customers to design once and interchangeably mount the JN3, SL869 or SL869 V2 depending on required features. The xL869 is Telit’s GNSS unified form factor family which allows customers to select among different GNSS technologies and feature sets. Modules in this family are offered in a 16 x 12.2 mm, 24-pad, LCC package.
When designing position-aware, connected devices, developers can also benefit significantly from the seamless integration between Telit cellular modules and the Jupiter SL869 V2. Bundling of all-Telit cellular and positioning modules significantly reduces development complexity without adding costs. Multi-GNSS modules applied together with the company’s eCall / ERA-GLONASS compliant cellular modules can, for example, deliver ready-to-use emergency automotive tracking solutions for the European and Russian markets.
