The new SENCORE modulator is a cost-effective two-channel, 1RU chassis that is designed to provide multistream satellite video delivery while minimizing overall transponder use. The product delivers one or two independent DVB-S2 modulations with up to six streams in each, a task that until now required additional or external equipment. The device accepts transport streams via DVB-ASI or IP inputs, which gives users the flexibility to accommodate changes over time. The SkyPHY-MSM is a customizable DVB-S2 forward link, multistream modulator IP core with a number of new features...
- Only IP core that can handle up to eight ASI input streams, with an architecture that allows for additional streams to be added as needed
- Each stream is independently configurable so users can choose the number of streams to be processed
- Eliminates the need for an external aggregator, which can reduce the amount of required rack space and lower overall capital expenditures
- Optimizes satellite bandwidth by aggregating multiple transport streams on a single satellite carrier to reduce operating expenses
The SkyPHY-MSM DVB-S2 Multistream Modulator IP is part of the family of DVB-S2 products offered by ViaSat, which includes the SkyPHY® ASIC and reference design, small form factor IRD (MIRD), high-speed SCPC modem (ELiTe-S2), and ECC9610 modulator.
