...microwave signal generator. These filters make it possible to achieve a harmonic suppression of more than –50dBc over a wide frequency range from 150MHz to max. 40 GHz. At low frequencies below 3GHz, it is even possible to achieve an excellent –58dBc.

The new harmonic filters efficiently improve the signal quality of the signal generator and consequently the measurement accuracy. In measurements with wideband receivers, the filters prevent the harmonics of the wanted signal from entering the receive band and affecting the measurement. In the case of total harmonic distortion measurements on amplifiers, the filters ensure that only the harmonics of the device under test are measured and not those of the signal generator. In addition, the dynamic range for scalar network analysis is improved considerably thanks to low harmonics at the generator end.

The R&S SMB-B25 harmonic filter option for the 20GHz model and the R&S SMB-B26 option for the 40GHz model are now available from Rohde & Schwarz.
